E-System
Motor: Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU)
Battery: Bosch PowerPack 400
Display: Bosch Purion, 4 mode selectable, walk assist
Range: 400 Wh: 42-85 km (26-53 mi)
Charger: 220V, 4A (EU)
Gears: 1 x 9
Weight: 29.3 kg (64.6 lb)
Bike Size: 187 × 70 × 102.5 cm (73.6 × 27.6 × 40.4 in)
Wheelbase: 130 cm (51.2 in)
Standover Height: 48 cm (18.9 in)
Seatpost to Handlebar: 60 - 64 cm (23.6 - 25.2 in)
Saddle to Pedal: 76 - 99 cm (29.9 - 39 in)
Suggested Rider Height: 155 - 190 cm (61 - 74.8 in)
Max Gross Vehicle Weight: 190 kg (418.9 lb)
Max Rider Weight: 120 kg (264.6 lb)
Frame: Tern Quick Haul Long, Patented Design, 6061-AL, DIN 79010 certified: 190 kg (419 lb)
Fork: Cargo, Aluminum alloy, DIN 79010 certified: 190 kg (419 lb)
Cockpit
Stem: Speedlifter, adjustable, 3D forged stem, 31.8
Headset: TH, cartridge bearings
Handlebar: Low riser ergo, 31.8, 6061-AL
Grips/Bar Tape: Velo ergonomic, lock-on
Saddle: Velo Comfort
Seatpost: 34.9 mm, 6061-AL, micro-adjust clamp
Seatpost Clamp: Tern Collar
Brakes
Front Brake: Tektro hydraulic disc
Rear Brake: Tektro hydraulic disc
Brake Levers: Tektro hydraulic disc
Wheels
Front Hub: Disc, aluminum
Rear Hub: 9 spd, disc, aluminum, Boost
Spokes & Nipples: Stainless steel
Rims: Tern Atlas H, cargo
Tyres: Tern x Schwalbe Super Moto-X, Green Guard puncture protection, Reflex
Transmission
Shifter: Tektro, 1 x 9 spd, trigger
Rear Derailleur: Tektro custom for Tern, 1 x 9 spd
Crankset: Tern custom, forged 6061-AL crankarm, anti-drop chainring
Cassette/Freewheel: Tektro 11-42T, 9 spd
Bottom Bracket: Motor integrated
Chain: KMC for eBike, 9 spd
Pedals: Urban with non-slip surface
Shifter Cable & Housing: SP
Bells & Whistles
Chainguard: SKS Chainblade
Kickstand: Atlas Kickstand, for cargo
Luggage Socket: Combo Mount
Front Light: 90 lux, StVZO approved
Rear Light: Herrmans
Fenders: SplashGuard, stainless hardware
Rack: Atlas L, 90 kg (198 lb) capacity
Frame Lock: Keyed-alike with Bosch battery
*Note: These are our standard model specifications. The bike's weight and folded dimension may not include racks and fenders. The specifications for your country may differ slightly. We do our best to ensure that the specifications listed here accurately reflect the exact parts found on our production bikes. However, component changes do occur for various reasons and there may be brief delays on site updates. We reserve the right to make component changes without prior notification, which may cause discrepancies with the information listed on the web.
