Frame
Orbea Rise Carbon LT OMR 2025, 150mm travel, 29" wheels, Concentric Boost 12x148
Shock
Fox Float X Factory 2-Pos Adjust Evol LV Kashima custom tune 210x55mm
Fork
Fox 36 Float Factory 160 Grip X QR15x110 Kashima
Steerer tube
Alloy 1-1/2", Black Oxidated Bearing
Ebike
Battery
Orbea Internal 420Wh
RANGE EXTENDER
N/A
Motor
Shimano EP801 RS Gen2 MC
Display
N/A
CHARGER
Orbea 2.Generation eBike Smart charger 42V/2-4A
Remote
EN600-L
Drivetrain
Chainring
e*thirteen Helix Core e*spec Direct Mount 32T 55mm ChainLine
Crank
Shimano Steps EM600
Shifters
Shimano SLX M7100 I-Spec EV
Cassette
Shimano CS-M7100 10-51t 12-Speed
Rear derailleur
Shimano XT M8100 SGS Shadow Plus
Chain
Shimano M7100
Chainguide
Orbea eBike chainguide
Cockpit
Handlebar
OC Mountain Control MC10 Carbon, Rise 20, Width 800
Stem
OC Mountain Control MC20, 0º
Computer Mount
OC Computer Mount CM-05, Garmin/Sigma
Brakes
Brakes
Shimano XT M8120 Hydraulic Disc
Rotors
Galfer Wave Rotors 203mm front / 180mm rear
Brakes Configuration
N/A
Wheels
Wheels
Oquo Mountain Control MC32TEAM
Tyres
Maxxis Assegai 2.50" 60TPI 3CG/EXO+/TR MaxxGrip
Tyres
Maxxis Minion DHR II 2.40" WT FB 120 TPI 3C MaxxTerra Exo+ TR
Components
Seatpost
OC Mountain Control MC22, 31.6mm, Dropper
Seatpost Lever
Shimano SL-MT500 I-Spec EV
Saddle
Fizik Terra Ridon X5 145mm
Grips
Ergon GE10
Accessories
Lights
N/A
Tools
OC FLP Multitool MT-20, Hex 2, 3, 4, 5 + OC Rear axle lever (Hex 6 & valve core removal)
