Frame
Orbea Denna, Thru Axle 12mm x 142mm rear, thread M12xP1, internal cable routing.
Fork
Orbea Denna OMR ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12xP1
Steerer tube
FSA 1-1/2" Integrated Aluminium Cup
Battery
Orbea Internal 420Wh
RANGE EXTENDER
N/A
Motor
Shimano EP801
Display
N/A
CHARGER
Orbea 2.Generation eBike Smart charger 42V/2-4A
Remote
EN600-L
Drivetrain
Chainring
Alloy EP8 42t
Crank
Shimano Steps EM600
Shifters
Shimano R9270
Cassette
Shimano CS-M8100 10-51t 12-Speed
Rear derailleur
Shimano XT Di2 M8150 12s SGS Shadow Plus
Chain
Shimano M6100
Orbea eBike chainguide
Handlebar
OC Road Performance RP11 Carbon, Reach 80, Drop 125, w/Di2 hole
Stem
OC Road Performance RP10, -8º
Brakes
Brakes
Shimano R9270 Hydraulic Disc
Wheels
Oquo Road Performance RP45TEAM
Tyres
Pirelli P ZERO™ Race X SmartEVO TLR 700x30c
Front Wheel Axle
Orbea Thru Axle 12x100mm M12xP1 Hollow
Rear Wheel Axle
Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded
Components
Seatpost
OC Performance XP10 Carbon, 27.2mm, Setback 0
Saddle
Selle San Marco Shortfit 2.0 Start Up Off Road Xilite
Accessories
Mudguard
N/A
Handlebar Tape
Lizard DSP 2.5mm
We reserve the right to make changes to the product and component information appearing on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materials.
