Frameset
Frame
Orbea Denna, Thru Axle 12mm x 142mm rear, thread M12xP1, internal cable routing.
Fork
Orbea Denna OMR ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12xP1
Steerer tube
FSA 1-1/2" Integrated Aluminium Cup
Ebike
Battery
Orbea Internal 420Wh
RANGE EXTENDER
N/A
Motor
Shimano EP600
CHARGER
Orbea 2.Generation eBike Smart charger 42V/2-4A
Remote
EN600-L
Drivetrain
Chainring
Alloy EP8 42t
Crank
Shimano Steps EM600
Shifters
Shimano GRX RX610
Cassette
Shimano CS-M7100 10-45t 12-Speed
Rear derailleur
Shimano GRX RX822 GS
Chain
Shimano M6100
Chainguide
Orbea eBike chainguide
Cockpit
Handlebar
OC Road Performance RP31-R, Rise 15, Reach 70, Drop 125
Stem
OC Road Performance RP23, -5º
Brakes
Brakes
Shimano RX410 Hydraulic disc
Brakes Configuration
N/A
Wheels
Wheels
Alloy, Tubeless, 700c, 21c
Tyres
Vittoria Terreno Dry Gravel G2.0 TLR 700x45c
Front Wheel Axle
Orbea Thru Axle 12x100mm M12xP1 Hollow
Rear Wheel Axle
Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded
Components
Seatpost
SP 0.2 Carbon, 27.2mm, Setback 0
Saddle
Selle San Marco Shortfit 2.0 Start Up Off Road
Accessories
Mudguard
N/A
Handlebar Tape
Orbea Anti-Slippery/Shock Proof
