Standard configuration
Frameset
Fork
Fox 34 Float AWL Sport 120 Rail 2.0, Kabolt 15x110, Fender and ABS Mts
Frame
Orbea Muga 2026, Hydroformed Alloy 6061, OLD 148, Belt drive compatible, Orbea cockpit and equipment ecosystem, w/ Custom Kickstand, Carrier compatible.
Shock
Fox Float Performance Trunnion 2-Pos custom tune 165x42.5mm
Headset
FSA 1-1/2" Integrated Aluminium Cup
Ebike
Motor
Bosch Performance Line CX BDU3843
Battery
Bosch Powertube 750Wh Horizontal BBP3770
Range Extender
N/A
Display
Bosch Purion 400
Charger
Bosch Charger 4A (230V) BPC3400
Remote
Bosch Mini Remote BRC3300
Drivetrain
Chainring
Gates CDX 48t w/chainguard
Crank
Prowheel EB03 alloy
Cassette
Gates CDX 24t for Enviolo
Rear derailleur
Enviolo Automatiq, BT
Chain
Gates CDX Belt
Cockpit
Handlebar
Orbea Urban, Integ. light, Backsweep 9, Rise 30, Width 760
Computer Mount
Smartphone mount SP Connect SPC+
Brakes
Brakes
Shimano MT520 Hydraulic Disc
Brakes Configuration
N/A
Wheels
Wheels
Alloy, 25c, 32H
Tyres
Schwalbe Johnny Watts Hybrid Radial TLR, 60-622, Radial, Addix Green, Reflective Tape
Tyres
Schwalbe Johnny Watts Hybrid Radial TLR, 60-584, Radial, Addix Green, Reflective Tape
Rear Wheel Axle
N/A
Components
Saddle
Selle Royal Vivo Ergo
Seatpost
OC Mountain Control MC22, 31.6mm, Dropper
Seatpost Lever
OC Dropper Remote for Sram Matchmaker
Accessories
Rear light
Supernova TL3 Z
Pedals
VP-892 Black with reflectors
Front carrier
N/A
Rear carrier
Orbea RR-02 Alloy, w/MIK HD and MIK Side and Ortlieb QL3.1 system. Max. 30Kg
Carrier accessories
N/A
Mudguard
Curana Apollo Orbit 70mm
Front Position Light
Orbea Integrated
Front light
Supernova Starstream Pro, High Beam
Quick stand
Orbea Integrated
