Standard configuration
Close
Frameset
Fork
SR Suntour XCR34 100mm Air Q15x110
Frame
Orbea Kemen Top bar 2027, Hydroformed Alloy 6061, High Polished, OLD 148, Belt drive compatible, Orbea cockpit and equipment ecosystem, w/ Kickstand, Trailer compatible.
Headset
FSA 1-1/2" Integrated Aluminium Cup
Ebike
Motor
Shimano EP600
Battery
Orbea 630 Wh Battery
Range Extender
N/A
Display
Shimano EN500
Charger
Orbea 2.Generation eBike Smart charger 42V/2-4A
Drivetrain
Chainring
Alloy 40t w/chainguard
Crank
Shimano Steps EM600
Shifters
Shimano Cues SL-U6000
Cassette
Shimano CS-LG400 11-50t 11-Speed
Rear derailleur
Shimano Cues U6000 GS Shadow
Chain
KMC eGlide
Cockpit
Handlebar
Orbea Urban, Integrated Light, Rise 50, Width 720
Computer Mount
Smartphone mount SP Connect SPC+
Brakes
Brakes
Shimano MT420 Hydraulic Disc
Brakes Configuration
N/A
Wheels
Wheels
Alloy, 26c, 32H
Tyres
Schwalbe Johnny Watts LR, 60-622, Reflective Tape
Rear Wheel Axle
N/A
Components
Seatpost
Alloy, 31.6mm, Setback 0
Saddle
Selle Royal Vivo Ergo
Accessories
Rear light
Supernova TL3 Z
Pedals
VP-892 with reflectors
Front carrier
N/A
Rear carrier
Orbea RR-02 Alloy, w/MIK HD and MIK Side and Ortlieb QL3.1 system. Max. 30Kg
Carrier accessories
N/A
Mudguard
Curana Apollo Orbit 70mm
Front Position Light
Orbea integrated, USB-C charging point
Front light
SUPERNOVA STARSTREAM PRO low beam
Quick stand
Massload rear adjustable
