Summary Components
Base price £ 7,299
Brakes Shimano R8170 Hydraulic Disc
Wheels Oquo Road Performance RP45TEAM (£ 0)
Tyres Vittoria Terreno Dry Gravel G2.0 TLR 700x45c
Frame Orbea Denna, Thru Axle 12mm x 142mm rear, thread M12xP1, internal cable routing.
Steerer tube FSA 1-1/2" Integrated Aluminium Cup
Handlebar Easton EC90 AX Carbon, flare 16º, Di2 internal routing
Stem OC Road Performance RP10, -8º
Shifters Shimano ST-8170
CHARGER Orbea 2.Generation eBike Smart charger 42V/2-4A
Front Wheel Axle Orbea Thru Axle 12x100mm M12xP1 Hollow
Chainring Alloy EP8 42t
Remote EN600-L
Rear Wheel Axle Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded
Brakes Configuration Left Road (£ 0)
RANGE EXTENDER Orbea Custom Range Extender 210Wh (+£ 395)
Cassette Shimano CS-M8100 10-51t 12-Speed
Rear derailleur Shimano XT Di2 M8150 12s SGS Shadow Plus
Chain Shimano M6100
Seatpost OC Performance XP10 Carbon, 27.2mm, Setback 0
Saddle Selle San Marco Shortfit 2.0 Start Up Off Road Xilite
Mudguard N/A
Chainguide Orbea eBike chainguide
Motor Shimano EP801
Battery Orbea Internal 420Wh
Handlebar Tape Orbea Anti-Slippery/Shock Proof
Crank Shimano Steps EM600
Display Shimano EN600 Cycle Computer (+£ 135)
Fork Orbea Denna OMR ICR, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12xP1
We reserve the right to make changes to the product and component information appearing on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materials.
